Multi Dimensional Config

​

Overview

GraphQL Multi-Dimensional Credential allows you to fetch user data via GraphQL APIs and validate eligibility across multiple dimensions. used to retrieve data for the extent of user participation.

​

Config process

​

1. Basic Config

• ID Type

ID Type provides various identity options, including social accounts, blockchain addresses, and other unique identifiers.

• Title

Give your credential an enticing title.

• Credential Source

Choose GraphQL type

• Type

Choose Multi Dimension

​

2. Specify Dimensions

In Multi-Dimensional Credential configuration, you need to define specific dimensions to ensure each dimension is clearly identified and usable.

• Identifier:

  • Enter a unique identifier for the dimension, e.g., mainnet_eth_balance.
  • The identifier is used for internal calls and logic operations, and it must be globally unique.

• Display Name:

  • Enter a display name for the dimension, e.g., ETH balance on Mainnet.
  • This name will be displayed in the UI for user understanding.

• Type:

  • Select the dimension type COUNTER from the dropdown menu.

• Description:

  • Enter a description to explain the purpose of the dimension, e.g., “This dimension tracks the ETH balance of a user on Mainnet”.
  • The description must be within 256 characters.

​

3. Configure API

• Input Endpoint Example:

https://api.example.com/query

• Add Headers (Optional)

`access-token`: `YOUR_TOKEN`

• Input Query:

query info($address: String!) {
    tokenBalance(address: $address) {
    balance
    }
}

​

4. Test API Response

• Input a test address and send the request to confirm the response:

  {
    "balance": 100
  }


​

5. Write Expressions

• Token Balance Output:

  function(resp) {
      return {
        "mainnet_eth_balance": resp.balance
      };
  }


​

6. Description

Description of the certificate, supports rich text input, maximum 200 characters.

​

7. Call-to-Action Link

Guide users to specific operation pages to complete interactive tasks.

​

8. Participation End Time && Update Frequency (Optional)

• Participation End Time:

Control the time range of the credential, prohibiting new validations after the deadline.

• Update Frequency:

Remind users of the frequency of API data source updates, such as once a day or once every two days.

​

9. Config Rule

Configure rules in Quest to determine whether users meet the criteria.

• Threshold Evaluation:

When a certain threshold condition is met (e.g., >0), assign a fixed points directly.

• Multiple Entries(Optional):

Enable users to claim rewards repeatedly once certain credentials are fulfilled, for example, a user earns 10 points for each 1 ETH they hold. If the user holds 5 ETH, they will earn 50 points.

​

Example

​

Galxe MSU Space points balance

• Specify Dimensions

Identifier:points_balance

Display Name:points balance on msu

Type:COUNTER

Description:The balance of points you hold on msu

• Endpoint

https://graphigo.prd.galaxy.eco/query

• Headers

No header

• Query

  query info($address: String!) {
      space(id: 68267) {
          addressLoyaltyPoints(address: $address) {
          points
          }
      }
  }


• Response

  {
      "space": {
      "addressLoyaltyPoints": {
          "points": 100
      }
      }
  }

• Expression

function(resp) {
 try {
    let points = BigInt(resp.space.addressLoyaltyPoints.points);
    return { "points_balance": points };
 } catch (error) {
    return { "points_balance": 0 };
 }
}
